Equipped with a large-capacity drive battery , the whole vehicle has a small kerb weight, a larger load mass, and lower driving energy consumption.
The unique sweeping vacuum cover and cylinder slider adjustment combined mechanism + central wide suction nozzle arrangement is adopted to solve the dust raising problem of the sweeping operation and sweep away the rubbish along the road;
Equipped with dry and wet switching control mechanism and suction switch adjustment mechanism of left and right cleaning devices, which realizes diversification of operation modes. According to different operation requirements, dry operation mode and wet operation mode can be used respectively. Adjust the opening of the left and right suction switch separately, with wide application range.
The dustbin of pure suction vacuum truck is made of SUS304 stainless steel as a whole, which will never rust.
The unique dustbin structure is adopted, and the maintenance and disassembly of the filter cartridge are simple and convenient. The inclined box structure of the garbage box is convenient for unloading without manual intervention.
The whole vehicle adopts 16 cone-shaped membrane filter cartridges with a filtration area of ≥160 square meters. The filter area is large and the suction effect is better. There is also a gas pulse filter cartridge cleaning device, which greatly improves the cleaning effect of the filter cartridge and can be effective. Reduce the clogging of the filter cartridge by dust and improve the operation effect; configure a large-capacity dust bin and dust removal box to improve the operation efficiency.
The electrical system is controlled by an integrated modular CAN bus. The panel has video functions such as fault diagnosis, digital testing, real-time display and monitoring of auxiliary engine speed, water temperature, operating conditions, etc. The operation status is clear and maintenance is easy.
Optional hydraulic oil heating device to ensure the normal operation of the hydraulic system in winter when it is severely cold.
Optional crushing device can be used to crush the fallen leaves on the road surface during the leaf-falling season to improve the vehicle cleaning effect.
Optional clear water tank, equipped with unloading spray dust reduction device, can effectively reduce the secondary dust caused by unloading.
