Use the combination of suction and sweeping, wet dust removal, electro-hydraulic control, hydraulic tipping and discharging to clean the road surface.
The use of pure electric chassis, electric drive fan and hydraulic oil pump has the advantages of large loading capacity, low noise and no emission pollution.
The most advanced electric power drive system, power battery system and electrical control system are adopted to meet the energy requirements of road sweeper driving and operation, maximize energy saving, and at the same time balance the load of the trough.
The transmission between the motor and the fan is provided with an automatic clutch, which can ensure that the motor is automatically disengaged from the fan during no-load start and stop, simplifying the operation, reducing the impact on the motor, and improving the working reliability and service life of the motor.
Adopt the structure arrangement of “centered two-disc brush + wide suction nozzle“, which is convenient for the adjustment and maintenance of the cleaning device and the suction nozzle, and at the same time saves the use cost of the brush.
The sweeper has an automatic avoidance protection function and an automatic reset function when encountering obstacles. It automatically retracts after encountering obstacles and automatically resets after crossing obstacles.
The rotating speed of the sweeping disk can be adjusted according to various cleaning conditions, and select high, medium and low gears, which can ensure a good cleaning effect under various pollution conditions.
It has a pneumatic net pipe antifreeze device, which can effectively ensure that the water spraying parts are not caused by structural damage due to icing.
Drainage and leakage prevention device can effectively prevent the accumulation of dirt, prevent secondary pollution caused by dirt falling back to the ground and clogging the garbage suction pipe.
The hydraulic system adopts superposed electromagnetic hydraulic valve group, which is highly integrated, neatly arranged, reliable in operation and convenient in maintenance.
All fasteners are galvanized. Scanning discs, suction nozzles and other structural parts are treated by pickling and phosphating after electrostatic spraying. They have strong adhesion, corrosion resistance and weather resistance.
The dustbin is made of SUS304 single layer whole stainless steel material, with high structural strength and no rust.
In the emergency state, the manual pump can be used to control the movement of the dustbin, suction nozzle and sweeping plate. In special circumstances, it can directly enter the auxiliary engine working cabin for inspection and maintenance.
It has various safety alarm devices: low water level of clean water tank, operation prompt, auxiliary engine water temperature, oil pressure, reverse prompt, hydraulic oil leakage alarm, dump box tipping, reset and rear door opening and closing safety alarm.
Using intelligent control system, centralized control of electric and hydraulic, simple operation, the driver can complete various actions in the cab.
