Natural Gas Washing & Sweeping Truck – FLM5180TXSDF6NGS

Using natural gas as fuel, natural gas vehicles are clean energy vehicles, which have the advantages of economy, environmental protection, safety and driving comfort.

The box body of the whole vehicle adopts the shape of a large curved surface on the side, with a circular arc transition, the box body is evenly stressed, the structural performance is strong, and the appearance is beautiful.

The working device adopts the “central four-disk scanning + central V-shaped water spray frame + central double suction nozzle narrow nozzle structure” layout form, with a variety of operating modes to achieve road cleaning, cleaning, washing and dust suction.

The original V-shaped nozzle and semi-circular suction nozzle without gap high-pressure nozzle layout effectively collect the cleaned sewage and garbage to the suction nozzle, and absorb it in the sewage garbage bin, so that the road surface will not leave dust and water , The pavement cleaning, brush sweeping and sewage recycling effect is good.

The sewage valve discharge device can effectively separate the sewage and sludge and discharge the sewage separately according to the sewage in the garbage bin at any time, effectively prolong the continuous operation time of the cleaning sweeper, and greatly improve the operation efficiency.

The clear water tank has a large volume and a long continuous operation time. At the same time, the sewage can be discharged through the sewage pipe during the operation, and the water can be added at any time to continue the operation; the large volume low-pressure nozzle is provided in the garbage bin, which can quickly rinse the garbage bin.

The hydraulic floating sweep distance automatic adjustment technology is used to keep the contact force of the sweep brush and the ground at a fixed value, and the contact surface of the sweep brush and the ground remains unchanged. After the sweep brush is worn, it can be automatically compensated without manual adjustment to ensure The cleaning efficiency is not affected.

Various safety alarm devices: low water level of clean water tank, high water level of sewage and trash bin, operation reminder, water temperature and oil pressure of auxiliary engine, reverse prompt, hydraulic oil leakage, dumping and resetting of garbage bin, safety alarm device for opening and closing rear door, etc.

Equipped with a low-pressure water system, the front nozzle has a high flushing pressure and can flush six lanes at a time; the left columnar side impact and the right columnar side impact device, the nozzle can be adjusted 360 ° left and right, 360 ° up and down.

Adopt CAN bus intelligent control system to realize intelligent centralized control of electricity, liquid and gas. The driver can complete various actions in the cab through the display screen and understand the vehicle operating conditions, operating parameters and fault information.

The left and right front scan discs and left and right water spray racks have automatic obstacle avoidance protection and reset functions.

Equipped with a pneumatic net antifreeze device, which effectively removes residual water in the waterway system, prevents the pipeline system from freezing and cracking at low temperatures, and improves the utilization rate of vehicles.

The high-pressure current collecting and cleaning nozzle can not only effectively flush the road surface but also absorb the cleaned sewage into the sewage garbage bin to improve the cleanliness of the road surface.
Adopt simple sand board structure, better simple and durable, easy to maintain.

The suction nozzle touch-down roller lifting adjustment and sweeping brush lifting adjustment adopt a quick and convenient structure, which makes the adjustment better and faster and more convenient.

Optional multi-angle single-point silt removal device, suitable for pavement rolling silt and dead angle garbage removal.
