As a new generation of garbage collection models, this truck has a breakthrough in its operation mode and can be equipped with a real-time garbage docking function and a high-pressure cleaning function. It is a multi-functional product with advanced performance, beautiful appearance, is durable and reliable, and can be widely used in urban blocks, residential quarters, and large factories and mines.
|
Main Parameters |
FLM5040ZDJNJBEV |
|
Chassis Model |
SH1047PCEVNZ |
|
Chassis Motor Model |
TZ249XSC7BY001 |
|
Chassis Motor Peak Power (kW) |
75 |
|
Chassis Motor Rotating Speed/Torque (r/min /N.m) |
5000/500 |
|
Chassis Battery Capacity (kWh) |
66.84 |
|
Chassis Battery Energy Density (Wh/kg) |
153.6 |
|
Rated Voltage/Capacity (V/Ah) |
386.4/173 |
|
Power Battery Type/Model |
Lithium Iron Phosphate Battery/LI 73TB1 |
|
Battery Manufacturer |
CATL |
|
Travel Range (km) |
276 |
|
Top Speed (km/h) |
90 |
|
Garbage Tank Dumping Angle (°) |
≥42 |
|
Garbage Tank Volume (m3) |
Model A (Standard Tank) 5.1/Model B (Split Tank) 2.16 (L+R) |
|
External Size (L*W*H) (mm) |
5105x1750x2125/5050x1715x2105 |
The tank body is made of stainless steel to ensure that it does not rust and that it has a long service life.
The tank body also has a side sliding door. This side door adopts a hanging rail structure, which is opened and closed by pushing back and forth. The feeding port is wide, easy to use and reliable.
The use of clean energy can reduce operating costs and has zero exhaust emissions, which is very clean and environmentally friendly. The truck is highly maneuverable and can be used for garbage collection in residential areas or small alleys.
The standard model is equipped with a glass fiber reinforced plastic sewage collection tank at the rear, which can collect and discharge sewage in a centralized manner, reducing dripping, sprinkling and leakage during transportation.
Optional waste separation and collection box with left and right compartments.
