This vehicle is a new generation road sweeper combining sweeping and suction developed by FULONGMA. It is mainly suitable for mechanized cleaning and sweeping operations in city streets, municipal squares, and large factories and mines. The truck has high operating efficiency, advanced and reliable technical performance, beautiful appearance, and has distinctive FULONGMA brand characteristics.
|
Parameters |
FLM5186TSLDG6 |
|
Chassis Model |
EQ1185LJ9CDE |
|
Emission Standard |
China VI |
|
Chassis Engine Model/Power (kW) |
D4.5NS6B220/162 |
|
Auxiliary Engine Model/Power (kW) |
4JB1-TCH/68 |
|
Gross Vehicle Weight (kg) |
18000 |
|
Top Speed (km/h) |
105 |
|
Sweeping Width (m) |
3.5 |
|
Sweeping Speed (km/h) |
5-25 |
|
Stainless Garbage Tank Volume (m3) |
8.5 |
|
Stainless Water Tank Volume (m3) |
3.7 |
|
Dimension (LxWxH) (mm) |
8000x2500x3140 |
It adopts the operation mode of a four-disc sweeper in the middle + built-in roller sweep nozzle at the rear for sweep and suction, wet dust removal, electro-hydraulic gas control, and hydraulic tipping and unloading. The sweeping pan has up to 3 operating modes: full sweep, left sweep (optional), right sweep (optional), to realize road cleaning and dust collection.
The garbage tank adopts a whole stainless steel single-layer structure, and the whole is not rusty.
The hydraulic system is used to control the movement of special working devices such as the expansion and lifting of the sweeping plate and the lifting of the suction nozzle. Compared with the pneumatic system control, the hydraulic system control has the characteristics of safety, reliability, and quick action response.
It has a pneumatic net pipe antifreeze device, which can effectively ensure that the parts of the water spray device will not crack due to icing and cause structural damage.
The sweeping brush grounding adjustment mechanism adopts chain adjustment control to ensure that the amount of contact between the sweeping broom and the ground is within a certain range. The mechanism is simple and reliable.
The sweeping speed can be selected according to different cleaning conditions, high, medium, and low three gears.
