This truck is a type of garbage collection and transportation equipment newly developed to meet the differentiated needs of users. This truck is suitable for areas where large vehicles cannot enter and areas that require low noise from sanitation vehicles. It’s useful in areas such as small streets, living quarters, factory and mine living areas, campuses, and other places, for front-end garbage collection and transportation.
|
Parameters |
FLM5070ZXXDG6 |
|
Chassis Model |
EQ1075SJ3CDF |
|
Emission Standard |
China VI |
|
Engine Model/Power(kW) |
CY4BK461/95 |
|
GVW (kg) |
7360 |
|
Lifting Capacity (t) |
3 |
|
Hydraulic System Rated Pressure (MPa) |
25 |
|
Dumping Angle (°) |
50 |
|
Dimension (Lx Wx H) (mm) |
5505x1960x2200 |
The truck integrates functions of loading, transportation, and self-dumping without auxiliary equipment. It is convenient and simple to operate.
One truck can be mounted with different containers for circular transportation to improve vehicle efficiency and reduce costs.
The hook arm system adopts a complete set of equipment, which is safe, reliable, lightweight, and has a large loading capacity. The hook arm system adopts a sliding arm articulated structure, which is convenient for hooking in, easy for maintenance, and has a smaller height limit for lifting and unloading containers.
The hook arm is made of a high-quality steel plate with high wear resistance and durability. The lifting hook is made of high-strength wear-resistant steel, which is firm and reliable.
The connecting parts of the chassis and the hook arm system are made of high-quality steel plates, which are safe, stable, and reliable.
All operations of the vehicle can be completed in the cab, and the operation is simple and convenient, which can reduce the labor intensity of the operator.
The cabinet is equipped with a safety lock, which is safe and reliable. The container of the truck will not shake during driving.
The truck can be optionally equipped with aluminum alloy side protection to lighter itself.
