The new generation of special vehicles for road cleaning developed by FULONGMA is mainly suitable for mechanized cleaning and sweeping of urban streets, municipal squares, large factories and mines. The whole truck has high efficiency, advanced and reliable technical performance, beautiful shape and distinctive brand characteristics of FULONGMA.
|
Parameters |
FLM5181TSLDG6NG |
|
Chassis Model |
EQ1185L9NDH |
|
Emission Standard |
China VI |
|
Chassis Engine Model/PowerfkW) |
YCA07220N-60/162 |
|
Auxiliary Engine Model/Power(kW) |
YCA07220N-60/162 |
|
GVW(kg) |
18000 |
|
Top Speed (km/h) |
89 |
|
Sweeping Width (m) |
3.5 |
|
Cleaning Capacity (㎡/h) |
105000 |
|
Washing Speed (km/h) |
5-30 |
|
Cleaning Rate (%) |
≥96 |
|
Stainless Steel Garbage Tank Volume (m3) |
≥8.75 |
|
stainless Steel Water Tank Volume (m3) |
≥3.25 |
|
Dimension (LxWxH) (mm) |
8915x2510x3470 |
This truck uses the latest exterior design to make the outline more appealing.
It adopts a central double-disc sweeper + wide suction nozzle to combine sweeping, suction, and blowing to perform dust removal, electro-hydraulic gas control, and hydraulic tilting and unloading operations. The sweeping pan has 3 operation modes: full sweep, left sweep, right sweep, which can sweep and vacuum the road surface. The safety brace can be automatically controlled, effectively reducing the incidence of accidents.
The disc sweeping device is driven by the air cylinder with adjustable pressure to ensure the ground contact pressure is within a reasonable range. The pan sweep is equipped with automatic obstacle avoidance, reset, and fall prevention functions. The fan is driven by a closed system hydraulic motor, which is not only sensitive and precise in control but also greatly improves the effective use of space in the vehicle. The use of large-volume trash cans, air circulation, and high-pressure water mist dust suppression technologies can effectively contain secondary dust while saving water. The speed of the sweeping disc can be adjusted easily depending on different working conditions to ensure a good cleaning effect under various pollution conditions.
