Kitchen garbage trucks are also known as after-dinner garbage trucks or swill trucks. Kitchen garbage trucks not only optimize the environmental sanitation of residents’ living, but also reduce the odor of kitchen waste in the air, reduce the possibility of breeding cockroaches, and improve sanitation. Work environment, reduce the pollution caused by the scattered garbage.
01. Basic configuration of a kitchen garbage truck
1. Arc-shaped box, the material of the box is 4mm.
2. Changyuan oil pump/Jiangsu multi-way valve/brand hydraulic cylinder.
3. Push shovel unloading (without lifting function), with dry and wet separation function, hydraulic back cover, back cover with sealing ring.
4. The rear door is hydraulically locked.
5. Pull-rod elevator, hanging 240L standard plastic trash can. Inlet covers hydraulic switch.
6. Centralized electronic control in the cab (manual control outside the hoist), the operation of the rear door locking and the rear cover switch is anti-misoperation.
7. The box is equipped with a cleaning device (hydraulic motor drives a high-pressure pump, with a water tank), and the kitchen cleaning device is optional.
02. Optional configuration of a kitchen garbage truck
1. Solid-liquid separation device: The separation device is equipped with a push head, which can be pushed from the front of the tank to the tail of the tank. The separation screen is made of 304 stainless steel.
2. Vacuum sewage suction function: when there is a large material pool, the vacuum sewage suction device can be used to directly remove the catering tank.
3. Heating device in the tank: diesel engine, carbon steel fire channel, set high and low-temperature values for automatic ignition and flameout heating, suitable for cold areas in winter so that the kitchen waste in the tank will not solidify due to too low temperature.
4. Optional PLC electronic control device one-key operation.
5. Install sealing discharge.
03. Advantages and characteristics of kitchen garbage trucks
1. Equipped with sewage collection, discharge, and flushing devices, which can initially achieve solid-liquid separation, drain and collect excess sewage and discharge it uniformly. It can also be connected to a fire hydrant pipe to flush the sewage tank, which is environmentally friendly and safe and improves the loading capacity and maintainability.
2. Equipped with tires to prevent vehicles from being unable to operate due to emergencies and improve maintainability.
3. The rear door cylinder seat is arranged vertically, which is convenient for installation and maintenance, and the sequence valve is used to realize the opening and closing sequence of the rear door and the bolt, which is reliable and reduces costs.
4. The special rear door rubber strip and rubber strip groove are used to prolong the service life of the rubber strip and improve the sealing performance of the rear door.
5. It adopts a special anti-drip device for the rear door to undertake the leakage of swill when the rear door is not sealed, with a simple structure, environmental protection, and safety.
6. Equipped with a rear door safety strut device, when the rear door is opened for maintenance, the safety strut will be propped up to prevent the rear door from accidentally falling down and improve safety.
04. Working video of a kitchen garbage truck
