FULONGMA’s small 7-ton road sweeper uses a combination of suction and sweeps to collect garbage, wet dust removal, electro-hydraulic control, and hydraulic tipping to clean the road surface. The sweeper has an automatic avoidance protection function and an automatic reset function when encountering obstacles. It automatically retracts after encountering obstacles and automatically resets after crossing obstacles, which can ensure a good cleaning effect under various pollution conditions.
01. Road sweeper chassis configuration
Adopt Dongfeng’s new chassis, wheelbase 3308mm, 7.00R16 steel wire tire, 5-speed gearbox, steering assist, electric doors and windows, central control lock, air brake, 2-ton front axle, 3-ton rear axle.
02. Standard on the road sweeper
Central 4-sweep, Jiangling 87 horsepower auxiliary engine, Sanyo motor, Schneider control switch, German Hybris solenoid valve group, continuously variable automatic clutch, maintenance-free centrifugal automatic fan, stainless steel trash can, electronic water pump, tail LED arrow indication Lights, manual pump emergency system, garbage lift dump function.
03. Performance characteristics of road sweeper
1. Diverse functions
The garbage is collected by means of suction and sweeping, wet dust removal, electro-hydraulic control, and hydraulic tipping and unloading are used to clean the road surface.
2. Main and auxiliary twin engines
The auxiliary engine is used to drive the fan and hydraulic system to ensure that it can continue to work during driving and to ensure the continuity of the cleaning process.
3. Reasonable layout
The structural layout of “central four sweeping discs + spray dust suppression device + central partition + rear suction nozzle” ensures that the sand and gravel will not splash and dust during the cleaning process. This layout is convenient for the adjustment and maintenance of the cleaning device and suction cups. The vehicle has good passability.
4. Long maintenance life
The transmission between the auxiliary engine and the fan is equipped with an automatic clutch, which can ensure the automatic separation of the auxiliary engine from the fan when it is started and stopped without load, reduces the impact on the auxiliary engine, and improves the working reliability and service life of the auxiliary engine.
5. Advanced technology
The sweeper has the automatic avoidance protection function and automatic reset function when encountering obstacles, and it automatically returns to its position when it encounters obstacles.
6. Intelligent frequency conversion
The rotating speed of the sweeping disc can be adjusted according to various cleaning working conditions, which can ensure a good cleaning effect under various pollution conditions.
7. Smart vacuuming
Adopt advanced and high-efficiency special fan and full-floating suction nozzle that can automatically adjust and balance with the road surface, with good cleaning effect and long service life.
04. Working video of road sweeper
