FULONGMA’s latest kitchen garbage truck is a new generation of domestic kitchen garbage truck boutiques created on the basis of absorbing the essence of similar kitchen garbage trucks and combining the existing research and development experience of kitchen garbage trucks. It is rebuilt by Dongfeng Class II chassis and is refitted with the addition of garbage bins, dozer assemblies, bucket lifting mechanisms, solid-liquid separation devices, hydraulic systems, and special-purpose electronic control systems. The product is beautiful in appearance, excellent in performance, advanced in operation and control, and its comprehensive performance reaches the advanced level of similar products.
01. Scope of application of kitchen garbage truck
It is mainly used to collect and transfer the kitchen waste generated by the catering industry, hotels, unit canteens, etc. It can also be used to collect and transfer kitchen waste and domestic waste in residential areas. ) to suit the needs of different users.
02. How to use the kitchen garbage truck
Open the sealing cover on the top of the garbage can, fix the kitchen garbage can at the position of the bucket lifting mechanism, and move the kitchen garbage (swill) bucket slowly along the fixed track to the feeding port by pushing the linkage connecting rod by the oil cylinder. The garbage (swill) is poured into the pretreatment area of the box body, and it is repeatedly sent to the kitchen waste resource treatment plant after being filled up. The entire process is automated, reducing manpower and making it easy to operate.
03. Structural characteristics of kitchen garbage trucks
1. The box body and rear door adopt arc shape, the whole vehicle is beautiful and elegant, and the main components box body, rear door, water tank, and screw machine are made of 304 stainless steel to ensure the high standard and high quality of the product.
2. The garbage box can realize the preliminary separation of solid and liquid food waste in the box, and use a large-volume sewage tank to increase the product loading capacity.
3. The dustbin and the back door are sealed with specially reinforced silicone strips, which have good sealing and prevent secondary pollution.
4. The electronic control system adopts three working modes, and interlocks through the operation action logic to ensure the accuracy of operation and prevent misoperation.
5. Fully automatic control of engine power output, reducing power loss and improving product economy.
6. Using a variable-speed electro-hydraulic proportional valve, the operation process can be automatically accelerated, and the upper cover is independently controlled, which greatly improves the operational efficiency of the product.
7. Equipped with a high-pressure, low-flow cleaning system driven by a hydraulic motor, which can clean the entire vehicle and working devices.
8. Electric and hydraulic key components adopt imported accessories to ensure product reliability. Equipped with work lights to ensure the safety of all-weather work.
9. “Screw” and “push” discharge methods are optional, and a “weighing” system and a “heating” system can be added according to customer needs.
04. Working video of a kitchen garbage truck
