Compression garbage trucks adopt electro-mechanical-hydraulic integration technology and adopt a mechanical, electrical, and hydraulic combined automatic control system. Through special devices such as carriages, fillers, and dozers, garbage can be loaded, crushed or flattened, and loaded with force, and then The garbage is compacted and squeezed into the carriage, and transported to the destination for automatic promotion and unloading.
01. Introduction to the advantages of compressed garbage trucks
1. The compression garbage truck produced by our company has the advantages of convenient garbage collection, automatically repeated compression and peristaltic compression, high compression ratio, large loading capacity, automatic operation, and good airtightness.
2. The compression garbage truck is a fully sealed type, and the sewage in the compression process directly enters the sewage tank to solve the secondary pollution during the garbage transportation.
3. Compression type garbage truck with hanging bucket lifting frame can be matched with iron hanging bucket or plastic hanging bucket for filling, squeezing the garbage into the compartment, compacting, and pushing off.
4. Economical: The computer controls the automatic fuel supply, and the fuel is automatically added during the compression operation at idling speed.
02. Working principle of a compression garbage truck
The power take-off is driven by the vehicle engine, and the gear pump is driven by the power take-off to provide power for the entire hydraulic system. The realization of each function on the vehicle can be controlled by operating the multi-way valve to control the expansion and return of each cylinder. In order to achieve garbage compression, shipment, and unloading.
The whole vehicle adopts mechatronics-hydraulic integration technology. With the help of a mechanical, electrical, and hydraulic automatic control systems, the garbage can be dumped, crushed, or flattened and filled through the carriage, filler, and push shovel, and the garbage can be squeezed into the carriage. And compact and shirk.
03. Structural Features of Compressed Garbage Truck
The compressed garbage truck is a garbage truck that can compress, compact, and reduce the size of garbage, which is advantageous for more loading. It is mainly composed of a second-class automobile chassis, a garbage container, a garbage filler, a turning mechanism, a hydraulic system, an electronic control system, etc. composition.
Optional configuration: add air conditioning in the cab, turn over rack or bucket at the rear, and PLC one-key control system.
