Sewage Cleaning & Purification Truck- FLM5070TWJQL6

The sewage cleaning & purify truck is a special vehicle used in septic tanks, construction site mud, breeding farms, river sludge, and other occasions that require solid-liquid separation. The truck integrates multiple functions such as sewage suction, waste separation, solid-liquid separation, and chassis power generation. The treated sewage can meet the discharge standard and be discharged to sewages directly. The extracted solid residue has a moisture content of less than 80%, which can be used as an organic fertilizer, turning waste into fortune.



Parameters

Parameters

FLM5070TWJQL6

Chassis Model

QL1070BUHACY

Chassis Engine Model/Power(kW)

4KH1CN6LB/88

Sewage Treating Volume (m3/h)

20

Moisture Content after Treatment

≤80%

Suction Pipe Range (m)

20

Rated Output of Generator Set (kW)

30

Extension of Input Cable (m)

33

Dimension (LxWxH) (mm)

5950x2080x2640

Dredge Water Pressure (bar)

160

Dredge Water Flow (L/min)

48

Dredge Pipe Length (m)

40

Features

The suction pipe is stored by a motor-driven reel. The pipeline has good airtightness, easy operation, and high efficiency.

It adopts garbage grid filtering and separation technology, which has low power and low noise. It has the characteristics of a good filtering effect, no clogging, is convenient, and has quick cleaning ability.

It adopts a lobe pump for direct pumping and direct discharge. It has advantages such as strong suction, high safety, low noise, no odor emission, and easy operation. Significantly improves processing efficiency and benefits.

The use of sludge filter press dehydration technology breaks through the disadvantages of slow operation and easy clogging of traditional screw stacking machines, never clogs, and greatly improves the discharge speed.

Equipped with a chassis power take-off power generation system is useful when there is no three-phase power at the worksite.

The equipment can work continuously and automatically, with high work efficiency, safety, and environmental protection. Effectively reduces the work intensity.

Equipped with high-pressure dredging and cleaning system, with diversified functions such as pipeline dredging and high-pressure cleaning, which greatly improves economic benefits.
