It’s the highly-efficient special purpose vehicle for washing road developed by Fulongma. It is mainly use low-level and smooth water flow to wash the dust on the road, and bring it down into the drainage pipe to achieve a clean and cooling effect. This truck has multi-function operation modes to be suitable for sanitation, municipal, landscaping work.
|
Vehicle fuel |
Natural Gas |
|
Tank Volume (m³) |
9.52 |
|
Sprinkler Head(m) |
50 |
|
Flushing width (m) |
≥24 |
|
Flushing Width (m) |
≥16 |
|
Rear high injection range (m) |
≥50 |
Using natural gas as fuel, natural gas vehicles are clean energy vehicles, which have the advantages of economy, environmental protection, safety and driving comfort.
A self-priming two-stage centrifugal pump is adopted, and the water pump is driven by the chassis engine to take power; it adopts the domestic first low-level flushing working mode.
The high water spray gun located at the rear of the body is flexible in operation and has a wide working angle range. It can be used to spray objects of various heights, and can remove some sanitation dead spots that are not easy to clean. It also has an auxiliary fire-fighting function, and the high water spray gun can be adjusted into a column or a mist.
Equipped with left-side columnar side punching and right-back columnar side punching device, the nozzle can be adjusted 360 ° left and right and 360 ° up and down.
Two nozzles are installed at the rear bumper, which are used for daily sprinkling to increase the humidity and reduce dust.
The switch control valves and sprinkler system pipes are made of corrosion-resistant materials. The tank body is made of Q235B steel plate, and the inside is treated by a special process to prevent corrosion. Stainless steel tanks are also available.
The vehicle is controlled by a highly reliable, pollution-free advanced pneumatic system, and all road work functions can be operated in the cab.
The structure is compact and reasonable, the water tank has large volume and long working time.
The water tank is equipped with a low water level sensor alarm system, which can automatically alarm when the water level is low.
Optional: such as rear upper spray, rear lower spray, sewer dredging device, left and right side watering, widened rear platform, single-point dredging, automatic water cannon, etc., to achieve multi-purpose vehicle.
