The new generation of combined sweeping and cleaning special vehicles developed by Fulongma is mainly suitable for the mechanized sweeping and cleaning operations of urban streets, municipal squares and large factories and mines. Fulongma brand characteristics.
|
Vehicle fuel |
Natural Gas |
|
Auxiliary Engine Model |
Yuchai YC4FA90N-50 |
|
Sweeping Width (m) approx. |
3.2 |
|
Dustbin Volume (m³) |
4.8 |
|
Water Box Volume (m³) |
1.8 |
Using natural gas as fuel, natural gas vehicles are clean energy vehicles, which have the advantages of economy, environmental protection, safety and driving comfort.
Cleaning device type: central four-disk scanning + rear suction nozzle, the scanning disk can automatically avoid obstacles.
Nozzle: Use a roller-sweeping enhanced nozzle with a built-in roller sweep to prevent the leakage of garbage; the three-point floating support of the rolling rubber wheel can adapt to the cleaning requirements of different road surfaces.
Pneumatic net pipe anti-freezing device can effectively ensure that the water spraying parts are not damaged by ice due to structural damage.
Drainage and leakage prevention device can effectively prevent the accumulation of dirt, prevent secondary pollution caused by dirt falling back to the ground and clogging the garbage suction pipe.
All fasteners are galvanized. Scanning discs, suction nozzles and other structural parts are treated by pickling and phosphating after electrostatic spraying. They have strong adhesion, corrosion resistance and weather resistance.
The dustbin box is made of SUS304 single layer whole stainless steel material, with high structural strength and no rust.
In the emergency state, the manual pump can be used to control the movement of the dustbin, suction nozzle and sweeping plate. In special circumstances, it can directly enter the auxiliary engine working cabin for inspection and maintenance.
The device with enhanced dust pressure function can adapt to the cleaning of thick dust roads.
It has various safety alarm devices: low water level of clean water tank, operation prompt, auxiliary engine water temperature, oil pressure, reverse prompt, hydraulic oil leakage alarm, dump box tipping, reset and rear door opening and closing safety alarm.
The auxiliary engine and the fan are connected by a centrifugal clutch, which can ensure that the auxiliary engine is automatically disconnected from the fan when the auxiliary engine is started without load and when the auxiliary engine is stopped.
Adopt CAN bus intelligent control system, electric and hydraulic centralized control, simple operation, the driver can complete various actions in the cab
