This truck is a special vehicle for efficient washing operations developed by FULONGMA. It mainly uses low-level water flow to flush road dust, achieving the effect of cleaning and cooling. The truck has a multi-functional operation mode and can be widely used in sanitation, municipal, and landscaping maintenance.
|
Parameters |
FLM5160GSSDG6 |
|
Chassis Model |
EQ1185LJ9CDE |
|
Emission Standard |
China VI |
|
Chassis Engine ModeL/Power (kW) |
YCS04200-68/147 |
|
Payload (kg) |
9615 |
|
Top Speed (km/h) |
105 |
|
Tank Volume (m3) |
≥10.09 |
|
Washing Width (m) |
≥24 |
|
Sprinkling Width (m) |
≥16 |
|
Rear Water Gun Range (m) |
≥50 |
|
Sprinkling Pump Head (m) |
110 |
|
Sprinkling Pump Flow (m3/h) |
50 |
|
Dimension (LxWxH) (mm) |
7390x2500x2800 |
It adopts a self-priming centrifugal pump. The water pump takes power from the chassis engine through the drive shaft. It works smoothly and has a high transmission efficiency.
It adopts a domestic first low-level flushing mode.
The high-pressure water gun located at the rear of the truck is flexible to operate and has a wide working angle range, which can be used for watering trees at various heights and positions. It also has an auxiliary firefighting function, and the spray can be adjusted into a column or mist shape.
Equipped with the adjustable front left and right sprinklers and rear left and right side nozzles. There are two rear sprinklers on the rear bumper, which are used for daily sprinkling to increase humidity and reduce dust on the road. Operation functions such as left and right side flushing, as well as front and rear sprinkling can be directly operated in the cab.
The control of the truck adopts a highly reliable, pollution-free advanced pneumatic system, and all road operation functions can be operated in the cab.
The structure is compact and reasonable, the volume of the water tank is large, and has a long operating time.
The water tank is equipped with a low water level sensor alarm system, which can automatically sound when the water level is low.
